TRiOCam-IPF Subsea IP Camera

The TRiOCam-IPF is a high-resolution subsea IP camera designed for underwater inspection, marine research, and integration into ROV and fixed subsea systems. It delivers reliable imaging performance in demanding marine environments.

Key Specifications

• Lens: 2.8 mm
• Horizontal angle of view: 106 in air, 77 in water
• Vertical angle of view: 56 in air, 41 in water
• Power: 12-30 VDC @ 300 mA
• Transmission protocols: H.264, H.265, ONVIF, RTSP
• Resolutions: 720p; 1080p; 1269p; 1440p
• Light sensitivity: 0.001 lx
• Depth ratings: 500 m; 4000 m

Key Features

• High-resolution imaging
• Low-light performance
• ONVIF and RTSP support
• Depth-rated subsea deployment

Typical Applications

• ROV inspection
• Fixed subsea monitoring
• Marine research
• Underwater observation

View Datasheet

Download STEP File
